Switch Harness With Charge B3P - 2000
Roll over to zoom in or click to enlarge
Switch Harness With Charge B3P - 2000

Futaba

Switch Harness With Charge B3P - 2000

$20.00
Code:TB2000
This is a Heavy Duty Switch Harness for Futaba Radios with J connectors.
It is intended for use in giant scale models with large numbers of
servos, especially those with high current draw (torque/speed/digital).

The switch harness connects the receiver battery to the receiver by way of an
ON/OFF switch. It also allows you to charge the receiver battery without
removing it from the model.

FEATURES

High Current Capacity 22AWG wire (normal is 24AWG)
Large Physical size and Connections for High Drain Uses

INCLUDES

One Switch Harness w/ J Connectors and Charge Cord.
Price: $20.00
Availability:
Enter a quantity:
Add to wishlist
Specs
Distance between mounting holes Ctr-Ctr: 28mm
Width: 39.2mm"
Thickness: 14mm
Height of switch body: 18.2mm
Height from bottom of switch body to tip of switch: 26.7mm
Battery Lead has a female Futaba J connector with a 6" lead
Charger Lead: has a female Futaba J connector with a 6" lead
Receiver Lead: has a male Futaba J connector with a 6" lead
