1/10 Stampede 4X4 XL-5 Brushed - RTR - 67054-1 B

The Stampede® VXL redefines high-performance for RC monster trucks. Extreme Velineon® brushless power muscles the Stampede to speeds of 65 mph and beyond with innovative Traxxas Stability Management® (TSM) to make the power more accessible. Experience speed and throttle response like you’ve never seen before in a monster truck. Pop a wheelie at 50 mph and you’ll appreciate the standard wheelie bar. Fully waterproof electronics ensure that Stampede VXL is ready for all-weather fun. Engineered for speed and built Traxxas Tough™, the Stampede VXL ushers in a new era of extreme performance.



QUICK FEATURES ON Stampede VXL (#36076-4):
Traxxas Stability Management
TQi™ 2.4GHz Transmitter and Receiver
Waterproof Electronics
Traxxas High-Current Connector
Maxx® Cable 12-Gauge Wiring
Digital High-Torque Waterproof Steering Servo
Magnum 272 Transmission with Steel Gears
Precision Steel Turnbuckles with Heavy-Duty Rod Ends
Metric Hex Hardware
Battery and Charger Sold Separately


Full Features list:

Traxxas Stability Management®
Powered by the Velineon® Brushless Power System
Stampede VXL reaches speeds in excess of 65mph!*
Traxxas High-Current Connector (patented) allows high-capacity battery packs to deliver maximum voltage to the Velineon Brushless Power System
Exclusive waterproof electronics extend brushless power and performance to water, mud, and snow.
Maxx® Cable 12-gauge wire
Velineon VXL-3s Electronic Speed Control
LiPo and NiMH compatible with two-stage low-voltage detection
Sport Mode – Forward / Brake / Reverse
Race Mode – Forward / Brake
Training Mode™ - 50% Forward / Brake / 50% Reverse (patented)
Velineon 3500 Brushless Motor
Consistent, high-power output, run after run
Low-maintenance, unique Traxxas design
Efficient, high-speed ball bearings
Precision-balanced rotor
TQi 2.4GHz transmitter
Compatible with optional TQi Traxxas Link Wireless Module (#6511) to access full Traxxas Link app functionality
Multi-Function knob
Adjustable steering and throttle percentage (dual rates)
Adjustable steering and throttle sensitivity (exponential)
Adjustable steering and throttle end points
High 13ms frame rate and near-zero latency for responsive control
TQi 2.4GHz 5-channel micro receiver (#6533) with Traxxas Stability Management and integrated telemetry ports
Digital high-torque Traxxas 2075 waterproof steering servo
Durable steel turnbuckles and captured rod ends
Efficient Magnum 272™ steel-gear transmission with ball bearings
Sealed gearbox protects the transmission with beefed up motor guard for extra protection
Torque-Control™ slipper clutch system
External gear cover with easy slipper access
Reliable composite planetary gear differential
Updated heavy-duty telescoping U-joint driveshafts and yokes
Fiber-composite monocoque chassis
Speed control and receiver are securely fastened to chassis
Easy access battery compartment
Fully adjustable Ultra Shocks™ with X-ring technology
White powder coated shock springs feature a responsive spring rate
Talon™ all-terrain 2.8" monster truck are pre-glued on black-chrome All-Star™ wheels
ProGraphix® multi-colored painted body
Stampede VXL is backed by unparalleled Traxxas support and parts availability


Specs:

Length: ­ 16.25 inches (413 mm)
Front Track: ­ 12.75 inches (324 mm)
Rear Track: ­ 12.75 inches (324 mm)
Weight: ­ 65.3 ounces (1.85 kg)
Height (Overall): ­ 9.5" (241 mm)
Wheelbase: ­ 10.63 inches (270 mm)
Front Shock Length: ­ Long
Rear Shock Length: ­ XXLong
Front Tires (Pre-Glued): ­ Talon™ 2.8"
Rear Tires (Pre-Glued): ­ Talon™ 2.8"
Front Wheels: ­ 2.8" Black-Chrome (All-Star™)
Rear Wheels: ­ 2.8" Black-Chrome (All-Star™)
Electronic Speed Control: ­ VXL-3s™ Electronic Speed Control
Motor (Electric): ­ Velineon® 3500 Brushless
Gear Ratio (Internal): ­ 2.72 (Final Drive: 12.34)
Differential Type: ­ Planetary
Gear Pitch: ­ 48-Pitch
Transmission: ­ Magnum 272™
Steering: ­ Single Point
Chassis Type: ­ Modified Tub
Chassis Material: ­ Composite Nylon
Radio System (Transmitter) ­ TQi™ 2.4GHz (2-Channel)
Radio System (Receiver) ­ Traxxas Stability Management™ (#6533)
Top-Speed: ­ 65+mph**
Skill Level: ­ 2
*Battery Tray Dimensions: ­ 164 mm x 46 mm x 26 mm
Required Items: ­ NiMH or LiPo battery, Charger, 4 "AA" (Transmitter)
*Battery expansion kit available (#3725X).
**With 3S LiPo battery and optional 30-tooth pinion gear (sold separately)


VXL-3s WATERPROOF ESC SPECIFICATIONS:
Input Voltage:   NiMH 4-9 Cells (4.8 to 10.8 Volts DC);
LiPo 2-3 Cells (7.4 to 11.1 Volts DC)
Case Size:   39 mm x 55 mm x 33 mm
Weight:   90 grams
Motor Limit (Brushless):   No motor limit
On Resistance Forward:   0.00075 Ohms
On Resistance Reverse:   0.00075 Ohms
BEC Voltage:   6.0 V
BEC Current:   2.5A
Power Wire:   12-Gauge Maxx® Cable
Input Harness Wire:   26 Gauge / 100 mm
Low Voltage Detection:   2-Stage indicators, switchable (on or off)
Thermal Protection:   2-Stage thermal shutdown
Profile selection:   Sport Mode:
    100% FWD, 100% BRAKES, 100% REV
Race Mode:
    100% FWD, 100% BRAKES, NO REV
Training Mode:*
    50% FWD, 100% BRAKES, 50% REV
Single-Button Setup:   Yes, Traxxas EZ-Set®
Battery Input Connector :   Traxxas High-Current Connector
Motor Types :   Brushless
Ports:   RX Input, auxiliary fan
For full details, click here. ­ *Patented


MODEL 36076-4: Fully assembled with Traxxas Stability Management®, TQi™ 2.4GHz
radio system, Velineon® Brushless Power System, and ProGraphix® painted body.
